Frame Set VELOBIKE M2 (UCI Legal)

Rámové sady Velobike M2 jsou na předobjednání napište nám pro zjištění dostupnosti.

Large - předobjednání

Medium - předobjednání

Small - předobjednání

Extra Small - předobjednání (zaslaní koncem června)

Dráhový rám, který vyniká skvělou pevností, tuhostí a aerodynamikou.

Velobike M2 Frameset je navržen tak, aby prořízl vzduch s malým odporem. Tuhá monocoque kompozitová konstrukce zajišťuje maximální přenos síly přes pedály se zanedbatelnými ztrátami.

Konstrukce rámu Velobike M2 pochází od uznávané organizace zabývající se designem jízdních kol. Velobike vlastní výrobní licenci UCI na sadu rámů.

M2 právoplatným konkurentem mezi dražšími rámovými sadami na trhu.

Navržen jako všestranná dráhová zbraň, exkluzivně pro Velobike složení karbonového rámu bylo optimalizováno pomocí vysoce modulového uhlíkového kompozitu T1000 v oblastech, kde je to nejvíce potřeba, a zároveň se snížila hmotnost v jiných částech rámu, aniž by byla ohrožena pevnost a tuhost. Tyto na míru vyrobené rámové sady jsou vyráběny na základě našeho rozsáhlého testování jak na testovacích zařízeních, tak na dráze.

• General specifications:

  • UCI approved
  • Sizes: XS, S, M, L, (XL not yet available)

  • Material: Japanese Toray T1000 (specific areas) and T700 Carbon Fibre

  • Finish: UD, Velobike M2 (2022 Livery)

  • Coating: matte clear

  • Weight: 1850g ± 50g (frameset and fork size large)
  • Built and tested to the ISO 4210 standards as a requirement for racing bicycle framesets.

  Component integration information:

  • BSA threaded bottom bracket

  • Clearance for up to 70 tooth Chainrings (42mm chainline)

  • 1 1⁄8" Steerer Tube

  • 100mm M9 front dropout spacing

  • 120mm M10 rear dropout spacing

  • Built-in rear axle tensioners

  • Replaceable rear dropouts

  • 700x25c tire clearance

  • Steel saddle rail mount (round). Carbon saddle rail clamp (oval) is available as an extra.

  Warranty information:

  • 2 year limited warranty

  Frameset includes:

  • UCI approved M2 Frame x1 (of chosen size)
  • UCI approved M2 Fork and Fork Topper x1 (of corresponding size to the frame)
  • M2 seatpost x1
  • Saddle clamp (steel saddle rails) x1
  • Seatpost clamp x1
  • Rear dropout plates x2
  • Headset bearings and bearing spacers x1 set
  • Headset compression plug x1

  Optional extras and spare parts:

  • M2 Fork
  • M2 seatpost
  • Carbon saddle rail clamp
  • Seatpost clamp
  • Rear dropout plates
  • Headset Bearings and bearing races
  • Headset spacers
  • Dropout protectors



English version:

Available for pre-order now, contact us for more information about availability and shipping. Contact us via email eshop@drahovky.cz for more information about delivery and availability to other countries outside the Czech Republic.

Large - available for preorder

Medium - available for preorder

Small - available for preorder

Extra Small - available for preorder (shipping late July 2023)

_____________________________________

A track frame that values strength, stiffness and aerodynamics.

The Velobike M2 Frameset is designed to cut through the air with little resistance. The stiff monocoque composite construction ensures maximum power transfer through the pedals with negligible losses.

The Velobike M2 frame design originates from a well regarded open-mould bicycle equipment design organisation. Velobike owns a manufacturing licence to the frameset, so we can assure our own performance characteristics and quality control practices.

The M2 is our transitional frameset before we release our own Velobike high-end proprietary frame design. The M2 serves as a top contender amongst other more expensive framesets on the market.

Designed as an all-round track weapon, the exclusive to Velobike carbon layup has been optimised using a high modulus T1000 carbon composite in the areas where its most needed, while reducing weight in other areas without compromising strength and stiffness. These custom made framesets are manufactured based on our extensive testing both in test rigs and on the track.

A ground-up re development of the front end for 2022 offers great universality of stem options for optimising bike-fits and general safety over the original front end assembly.

Ridden by Shane Perkins

General specifications:

• UCI approved
• Sizes: XS, S, M, L, (XL not yet available)

• Material: Japanese Toray T1000 (specific areas) and T700 Carbon Fibre

• Finish: UD, Velobike M2 (2022 Livery)

• Coating: matte clear

• Weight: 1850g ± 50g (frameset and fork size large)
• Built and tested to the ISO 4210 standards as a requirement for racing bicycle framesets.

Component integration information:

• BSA threaded bottom bracket

• Clearance for up to 70 tooth Chainrings (42mm chainline)

• 1 1⁄8" Steerer Tube

• 100mm M9 front dropout spacing

• 120mm M10 rear dropout spacing

• Built-in rear axle tensioners

• Replaceable rear dropouts

• 700x25c tire clearance

• Steel saddle rail mount (round). Carbon saddle rail clamp (oval) is available as an extra.

Warranty information:

• 2 year limited warranty

Frameset includes:

• UCI approved M2 Frame x1 (of chosen size)
• UCI approved M2 Fork and Fork Topper x1 (of corresponding size to the frame)
• M2 seatpost x1
• Saddle clamp (steel saddle rails) x1
• Seatpost clamp x1
• Rear dropout plates x2
• Headset bearings and bearing spacers x1 set
• Headset compression plug x1

Optional extras and spare parts:

• M2 Fork
• M2 seatpost
• Carbon saddle rail clamp
• Seatpost clamp
• Rear dropout plates
• Headset Bearings and bearing races
• Headset spacers
• Dropout protectors

Velobike_M2_User_Manual_09-01-2023
